J Hook Clamp - Medium (10-16 mm)

Top Selling Products

Access Terminal Box (ATB) - Loaded with SCUPC simplex adapters and pigtails

KES179.80
Aluminium Universal Pole Bracket (UPB)

KES226.20
ADSS Tension Clamps ( PA 1500 )

KES380.48
Stainless Steel Straps

KES2,700.48
ADSS Tension Clamps ( PA 2000 )

KES450.08
J Hook Clamp - Medium (10-16 mm)

KES450.08

Reviews & Ratings

0 out of 5.0

(0 reviews)

There have been no reviews for this product yet.

Description

J Hook Suspension Clamp 10~ 15mm is designed to suspend ADSS round optical fiber cable during construction of the transmission line. The clamp consists of a plastic insert, which clamps the optical cable without damaging it. A wide range of gripping capacities and mechanical resistance achieved by a wide product range, with different sizes of neoprene inserts. The metal hook of suspension clamps allows installation on the pole by using a stainless steel band and pigtail hook or brackets.

Main Features

Installation in just a few seconds with a 13 mm standard 6 point spanner
The shape of the J Hook allows a running out of the cable directly in the hook
The suspension clamps can be directly secured to the poles using bolts or bands.

They can also be installed on hook bolts to provide some flexible suspension point and give extra protection to the cable against wind induced vibrations

Specification

Cable span: span up to 100 meters.
Breaking Load (KN): 12Kn
Suitable for cable: 10~16 mm ADSS cable
material: Aluminum, Plastic
insert: Protected Neoprene
Screw: protected steel
packaging Requirements; carton - 50pcs/carton
Processing Technology: Forming

Application: J hooks offer cable support for all types of telecommunications and power cabling such as category cables, optical fiber cables and coax cables.
